12V/24V 20A Solar Charge Controller

12V/24V 20A Solar Charge Controller


100000 in stock

SKU: C2430 30A Category:

C2430 20A

Charge Controller
battery controller, solar system controller) applies in solar photovoltaic
systems, which coordinates the operation of solar panels, batteries and loads.
It adds more protection functions, so the entire system can be more efficient
and safe in operation.

MCU (Micro-Processing Controller) has PMW (Pulse Modulation Wide-frequency)
0~100% variable duty cycle process. According to the types and actual charging
situation of the battery, C2430 solar charge controller series (solar power
controller, solar charge regulator, solar battery controller) can provide the
fast and best charging voltage and electricity from the PV panel.


  1. CPU control, LCD display
  2. Automatic recognition of input voltage
  3. Applicable to various types of durable batteries
  4. Micro processing controller Pulse Modulation Wide-frequency ( PWM)charge
  5. Setting the voltage of low voltage cut-off/resuming connection of the DC
    output of the load port
  6. Temperature sensor for charging a battery in compensation
  7. Protective circuit of PV from reverse-charging.
  8. Overloading protection
  9. Overcharge protection
  10. Short circuit protection
  11. The temperature compensate
  12. Reverse polarity connection protection
  13. Converse discharge protection
  14. Thunder protection
  15. Low voltage protection

Technical Details:

  1. Model:C2430
  2. Rated Voltage:12V/24V Automatic voltage recognition
  3. Max load current:20A
  4. Input Voltage:12V~17V/24V~34V
  5. Length≤1m,Charge loop drop:<0.25V
  6. Length≤1m,Discharge loop drop:<0.05V
  7. Over voltage protection:17V/34V
  8. Full charge cut:13.7V
  9. Low voltage cut:10.5V~11V / 21V22V
  10. Temperature compensation:-3mv/°C/cell
  11. No load loss:≤20mA
  12. Max wire area:4mm2
  13. Ambient temperature:-25°C—+55°C

Package Contains

Solar Charge Controller C2430 12V/24V 20Amp

User manual

Additional Information

Weight600.00 kg
